Save Time and Manpower: As the hopper body and bottom are designed separately, and therefore it is very convenient to clean materials and quite simple and quick to renew materials as well. A, L feet frames, receiver of hot air, the filter of inlet of fan, the filter of air exhauster, magnetic base, magnetic iron of bunker, and European material box are available for selection. Well-distributed Heated Wind: The heat efficiency is high enough to shorten great amount of drying time.
Features
- Precise Temperature Controls: The precise temperature controls ensure and keep a high accuracy of temperature.
- The Trustworthy Design: Fine exterior, solid construction. Short material-melting time greatly helps to promote the spouting speed.
- Increase injection ratio: direct heating blanking, shorten material melt time, and promote the injection ratio.
- Automatic control time: setting on/off freely 24 hours around, automatic working.
Technical Parameter
| Model | Diameter (mm) | External size (mm) | Capacity (kg) | Heater power (kw) | Applicable injectioner (0Z.) |
|---|---|---|---|---|---|
| XHD-12KG | Ø280 | 640x430x780 | 15 | 2.1 | 1 |
| XHD-25KG | Ø350 | 760x500x900 | 25 | 3.5 | 3 |
| XHD-50KG | Ø430 | 840x540x1030 | 50 | 4.8 | 5-8 |
| XHD-75KG | Ø468 | 950x600x1140 | 75 | 5.1 | 6-9 |
| XHD-100KG | Ø550 | 1080x700x1250 | 100 | 7.8 | 10-30 |
| XHD-150KG | Ø630 | 1120x760x1300 | 150 | 8.88 | 15-30 |
| XHD-200KG | ø700 | 1250x850x1480 | 200 | 10 | 30-60 |
| XHD-300KG | Ø750 | 1300x920x1740 | 300 | 15 | >60 |
| XHD-400KG | Ø800 | 1400x1040x1760 | 400 | 20 | >60 |
| XHD-600KG | Ø990 | 1600x1150x2150 | 600 | 27 | >60 |
| XHD-800KG | Ø1090 | 1700x1330x2660 | 800 | 30 | >60 |
| XHD-1000KG | Ø1090 | 1700x1330x2860 | 1000 | 32 | >60 |
| XHD-1500KG | Ø1300 | 2100x1400x3000 | 1500 | 48 | >60 |
About us
We have more than 20 years knowledge and experience on PET Water/juice/carbonated drinks production line.
Our exporting product includes: Injection molding machine, PET preform mould, plastic bottle blowing machine, Water treatment system, water bottle filling machine and Packaging machine etc.
Q: What is the warranty if we buy your machines?
A: We offer the high quality machines with 1 year guarantee start from the machine reach to your factory. Also your share the lifelong technical support.
Q: How about the spare parts?
A: We will send one year enough spare parts together with machines for your stock. During the warranty time, if some spare parts broke without human problem, we will send free for you.
Q: How to install my machines when it arrives? What is the cost?
A: We will send our engineer to your factory to install the machines and train your engineers how to operate and maintain the machines. Customer pay for visa, round-trip tickets, room and accommodation, also USD80/day/ person(engineer salary).
Q: How long time for installation?
A: According to the machine you order, usually we will send one or two engineer, it takes about 7to 20days.
Q: When can I get my machine after I paid?
A: Usually the production time is around 25-60 days. The exactly will be decided by which machine u order.
